ASUTEC ASU-400-EW-09-100 Pneumatic Conveyor Stop Module

Original ASUTEC pneumatic stop module designed for stopping and separating workpiece carriers and pallets in industrial conveyor and transfer systems.

The ASU-400-EW-09-100 belongs to the ASU-400 series of pneumatic stop modules without damping.

It features a single-acting pneumatic mechanism with spring return. Compressed air lowers the stop into the release position, while the internal spring returns it to the blocking position when pressure is removed.

This design enables controlled stopping and release of workpiece carriers in automated production and material-handling systems.

Technical Specifications

• Manufacturer: ASUTEC
• Model: ASU-400-EW-09-100
• Series: ASU-400
• Product Type: Pneumatic conveyor stop module
• Function: Workpiece carrier stopping and separation
• Actuation: Single-acting pneumatic
• Return Mechanism: Spring return
• Lowering Stroke: 9 mm
• Damping: Without damping
• Maximum Workpiece Carrier Load: Up to 400 kg, depending on conveyor speed and operating conditions
• Maximum Propulsive Force: 307 N at 6 bar under specified manufacturer conditions
• Pneumatic Connection: M5
• Mounting: Side mounting holes for M8 screws
• Operating Temperature: -20°C to +80°C, standard version
• Country of Origin: Germany

Operating Principle

The stop module remains in the raised blocking position when pneumatic pressure is absent.

Applying compressed air lowers the stop, allowing the workpiece carrier to continue moving.

When pressure is removed, the spring returns the stop to its blocking position.

Condition

Used, fully functional.

The unit shows signs of previous industrial use.

Included

• 1 × ASUTEC ASU-400-EW-09-100 pneumatic stop module
• Installed pneumatic push-in elbow fitting
• Attached metal stop element

Only the components shown in the photographs are included. Additional mounting hardware is not confirmed.

Applications

Suitable for industrial conveyor systems, pallet transfer lines, workpiece carrier positioning, assembly automation, and automated material-handling equipment.

Compatibility with a specific conveyor system should be verified before purchase.
